Company Introduction:
Zhejiang Qianxilong Special Fibre Co.,Ltd.is located in Yongkang Economic Developing Zone, Zhejiang China. Invested and established by "Qunsheng Group" in 2009 ,we're a high-tech enterprise which R&D,manufactures and sales UHMWPE fiber(ultra high molecular weight polyethylene fiber ).Covering an area of almost 140,000 square meters ,our company plans to enlarge annual production capacity to 5500 tons .With a full range of specifications ,our products have been widely used in many fields, including national defense equipment ,aviation and aerospace ,safety and protective equipment ,medical materials ,pelagic fishing ,mooring rope ,sporting goods ,building materials etc.
In accordance with business concept "technology promotes company ,quality determines market", our company builds up professional R&D team and first -class inspection center .Quality stability is guaranteed by a few national patents ,completely-owned intellectual property, sound production method and full-automation integrated control .
Insisting on operation principal as "quality first, Honest business, From better to best ,trends leading ", we keeping pursuing the aim of providing customers with satisfactory products and service.
Production Introduction:
I. UHMWPE fiber
UHMWPE yarn is one of three major hi-tech fibers ( specifically the carbon fiber,aramid,and UHMWPE) , in addition ,it is a super strong polyethylene fiber that offers maximum strength combined with minimum weight. It is up to 10 times stronger than quality steel and up to 40% stronger than aramid fibers, both on weight for weight basis. UHMWPE yarn floats on water and is extremely durable and resistant to moisture, UV light and chemicals. The applications are therefore more or less unlimited.
Specification | Fibre number | Breaking tenacity | Breaking modulus | Breaking elongation |
dtex | cN/dtex | cN/dtex | % | |
QXL-10D | 11 | ≥40 | ≥1500 | ≤3.5 |
QXL-15D | 17 | ≥40 | ≥1500 | ≤3.5 |
QXL-20D | 22 | ≥40 | ≥1500 | ≤3.5 |
QXL-25D | 28 | ≥40 | ≥1500 | ≤3.5 |
QXL-30D | 33 | ≥40 | ≥1500 | ≤3.5 |
QXL-40D | 44 | ≥40 | ≥1500 | ≤3.5 |
QXL-50D | 55 | ≥40 | ≥1500 | ≤3.5 |
QXL-75D | 83 | ≥38 | ≥1400 | ≤3.5 |
QXL-100D | 111 | ≥35 | ≥1350 | ≤3.0 |
QXL-125D | 139 | ≥35 | ≥1350 | ≤3.0 |
QXL-150D | 165 | ≥34 | ≥1300 | ≤3.0 |
QXL-175D | 193 | ≥33 | ≥1250 | ≤3.0 |
QXL-200D | 222 | ≥33 | ≥1250 | ≤3.0 |
QXL-225D | 248 | ≥33 | ≥1250 | ≤3.0 |
QXL-250D | 275 | ≥33 | ≥1250 | ≤3.0 |
QXL-300D | 333 | ≥32 | ≥1200 | ≤3.0 |
QXL-350D | 389 | ≥32 | ≥1200 | ≤3.0 |
QXL-400D | 444 | ≥32 | ≥1200 | ≤3.0 |
QXL-500D | 555 | ≥32 | ≥1200 | ≤3.0 |
QXL-600D | 667 | ≥32 | ≥1200 | ≤3.0 |
QXL-700D | 777 | ≥30 | ≥1100 | ≤3.5 |
QXL-800D | 889 | ≥30 | ≥1100 | ≤3.5 |
QXL-1000D | 1111 | ≥30 | ≥1100 | ≤3.5 |
QXL-1200D | 1333 | ≥30 | ≥1100 | ≤3.5 |
QXL-1400D | 1554 | ≥30 | ≥1100 | ≤3.5 |
QXL-1600D | 1778 | ≥30 | ≥1100 | ≤3.5 |
QXLG-800D | 889 | ≥34 | ≥1200 | ≤3.5 |
QXLG-1200D | 1333 | ≥34 | ≥1200 | ≤3.5 |
QXLG-1600D | 1778 | ≥34 | ≥1200 | ≤3.5 |
Basic features of UHMWPE yarn are following .
*High strength: 10 times stronger than the high-quality steel of the same section in intension;
*High modulus: next to the super-class carbon fiber
*Low density: 0.97, and floatable on water
*Anti-UV
*Anti-erosion---anti-acerbity,anti-alkali,anti-seawater;
*Extraordinary anti-abrasive,flexible,anti-bend .
Based on UHMWPE yarns so advantageous properties,it has now become one of the high-tech materials rapidly developed in recent years and widly applied in such fields as safety protection,aviation,spaceflight,navigation,electronics,weapon,shipbuilding,building material,sports,medical treatment and so on . Products made up of the fiber include bulletproof jacket,ballistic helmet,financial vehicle,ballistic shield,tank,naval armor protection board,parachute hawser,watercraft oceaneering cordage,mountain-climbing rope,fishing net and tread,boat,gig and arrow,pat,ski,man-made nearthrosis and ligament,safety protection cover,anti-impact vessel and so on.
II. UHMWPE Characteristics
1-UHMWPE fiber woven
2-high tensile strength
3-can use any denier fiber, make any weight
4-UV,abrasion,water resistance
5-Non-Toxic
6-Good quality
7-Low coefficient of friction
8-UHMW exhibits virtually no water absorption
9-Corrosion resistant
10-Abrasion and impact resistant
11-Wear Resistant
12-Great liner material for industrial material handling applications
III. UHMWPE Application
1. Chemical Engineering: Corrosion and wear resistantance mechanical parts
2. Thermal power: coal handling, storage of coal, warehousing chute lining
3. Coal processing: sieve plate, filter, U-underground coal chute
4. Concrete: cement raw and finished product silo silo lining
5. Grain: food storage or chute lining
6. Mining: sieve plate, chute linings, wear anti-bonding part
7. Textile:Strong thermal conductivity brings continuous cooling
7. Food industry: star-shaped wheel, transmission timing bottle screw, bearings, guide
rollers, guides, slide blocks, etc.
20D-400D: Fishing line, fishing net, dental floss, medical suture, UD fabric
400D-600D: Cut-resistant glove, glove, ballistic UD fabric, bulletproof vest/jacket
600D-1600D: Mooring rope, rope, sailing rope, marine rope
Packing &Delivery:
Two ways to package for choose
![Green New High Tenacity UHMWPE Fabric 150d](https://img3.grofrom.com/honzo/b471035e3d7fcfedf934279f627af55d.webp)
![Green New High Tenacity UHMWPE Fabric 150d](https://img3.grofrom.com/honzo/822256bf0c09e31d21776652667e5568.webp)
Our Certification:
FAQ:
Q1. Are you a factory?
A:Yes, we are the manufacturer.
Q2.How about your delivery time?
A:Normally,it will take 3 to 6 days after receiving the deposit.It depends on the items and the quantity of your order.
Q3:Can you arrange production according to samples?
A:Yes,we can produce by your samples or drawing.
Q4:What is your sample policy?
A:If the quantity is small,the samples will be free,the customers just should pay the express fee.
